| Microscope Optical Data Sheet |
| P/N |
Objective |
Objective Working Distance |
Eyepiece |
| FS05031321 (10X Dia. 20mm) |
SZ05033411 (15X Dia. 15mm) |
SZ05033611 (20X Dia. 10mm) |
SZ19013711 (25X Dia. 10mm) |
SZ19013811 (30X Dia. 8mm) |
| Magnification |
Field of View(mm) |
Magnification |
Field of View(mm) |
Magnification |
Field of View(mm) |
Magnification |
Field of View(mm) |
Magnification |
Field of View(mm) |
| FS05031321 |
2/4X |
100mm |
20/40X |
10/5mm |
30/60X |
7.5/3.75mm |
40/80X |
5/2.5mm |
50/100X |
5/2.5mm |
60/120X |
4/2mm |
| 1. Magnification=Objective Optical Magnification * Body Magnification * Eyepiece Optical Magnification |
| 2. Field of View=Eyepiece Field of View /（Objective Optical Magnification*Body Magnification） |
| 3. The Darker background items are Standard items, the white background items are optional items. |
