Baader T-2 BBHS Mirror Diagonal (MAX-1S)

Baader T-2 BBHS Mirror Diagonal (MAX-1S)

$185.47 USD
$289.79 USD $185.47 USD
Sale Sold out
Shipping calculated at checkout.

Baader T-2 BBHS Mirror Diagonal

  • T-2 BBHS star diagonal withT-2 threads for compatibility with all Baader's Astro T2 system of parts
  • Provides high reflectance over a wide spectral range from 390 to 2000nm to give high color fidelity
  • Higher in brilliance and lower scatter than cheaper dielectric coatings
  • BBHS = BroadBand HardSilver coating with dielectric protective overcoating
  • Sitall glass-ceramic zero expansion mirror won't lose its flatness even during extreme temperature changes


Technical Specifications

MANUFACTURER Baader Planetarium
SKU (#) 2456103
OPTICAL DESIGN Mirror Diagonal
OUTER CONNECTION (LENS SIDED) Thread, T-2 (M42 x 0,75)
INNER CONNECTION (EYEPIECE/-CAMERA-SIDED) Thread, T-2 (M42 x 0,75)
REFLECTION SURFACE BBHS coated, Dielectrically protected
IMAGE ORIENTATION Erect image, Mirror inverted
OPTICAL LENGTH (MM) 43
CLAMPING SYSTEM no clamp
DEFLECTION ANGLE 90°
INNER DIAMETER / CLEAR APERTURE (MM) 33

In the Box

  • Baader T-2 BBHS Mirror Diagonal

      Warranty & Manuals

      2-Year Warranty
